Enhanced Performance for ICP-MS and ICP-OES
The IsoMist programmable temperature-controlled cyclonic spray chamber features an improved thermodynamic design providing an extended temperature range and faster cool-down so your ICP application is ready to go sooner.
The IsoMist is a compact, convenient and maintenance-free temperature-controlled sample introduction system for all ICP-OES and ICP-MS.
Product Features
- High quality and consistent plating of our coils promotes extended coil life
- Each coil is supplied on a plastic former ensuring correct dimensions and easier installation
- Each coil is supplied in a special protective container to ensure correct dimensions are maintained, and the coil arrives corrosion free
- Correct alignment of the coil with respect to the torch body reduces devitrification of the outer tube
- Reusable alignment tools ensure correct installation every time. Our CD with Do-It-Yourself instructions saves time
- Regular replacement of corroded coils reduces the load on the RF generating system
- Changing corroded coils increases enery transfer, resulting in a more robust plasma and generally higher analytical line intensities
Reduce Oxide Formation in ICP-MS
Using the IsoMist spray chamber at sub-ambient temperature on an ICP-MS, the sample is cooled so less water vapor is transferred to the plasma resulting in lower oxide formation and reduced polyatomic interferences - improving accuracy and detection limits.
Perfect for Volatile Organics
When analyzing volatile organic solvents such as naphtha and gasoline a lower sample introduction system temperature reduces nebulization efficiency avoiding quenching of the plasma from solvent over-loading. With a minimum temperature of -25°C analyzing volatile organic solvents is even easier.
Constant Temperature Improves Analytical Stability
Fluctuations in the lab temperature affect sample viscosity and nebulization efficiency. Maintaining the sample introduction system at a constant and stable temperature improves analytical reproducibility, enhances throughput, and lowers operating costs by reducing the need to re-run samples when a calibration verification check standard (Figure 2.) drifts outside the acceptable upper or lower limits.
Elegant, Ergonomic Design
The IsoMist XR is an elegant, compact, stand-alone system manufactured from inert materials resistant to attack from acids and solvents commonly used in ICP analysis. By using a Peltier thermo-electric device to maintain the spray chamber temperature, the messy, noisy, and high-maintenance refrigerated, recirculating baths used with jacketed spray chambers are eliminated. The compact design also means the IsoMist XR Programmable Temperature Controlled Spray Chambers are compatible with any ICP-OES and ICP-MS.
